Platinum Metals Rev., 2013, 57, (4), 311
doi: 10.1595/147106713X672221

PGMs in the Lab: New, Efficient Tools for Palladium-Catalysed Functionalisation of Heteroaromatics

Johnson Matthey and Alfa Aesar support new platinum group metals research



Here another researcher whose work has benefited from the support of Johnson Matthey and Alfa Aesar, A Johnson Matthey Company, is profiled. Jean-Cyrille Hierso is a Full Professor and Member of the Institut Universitaire de France (IUF) at the University of Burgundy in Dijon, France. He is interested in metal and ligand chemistry, catalysis and nanomaterials.

About the Researcher



Professor Jean-Cyrille Hierso

* Name: Jean-Cyrille Hierso

* Position: Full Professor – Member of the Institut Universitaire de France (IUF)

* Department: Institute of Molecular Chemistry – Mixte CNRS Unit 6302

* University: University of Burgundy

* Street: 9 Avenue Alain Savary – Faculté Mirande

* City: Dijon

* Post or Zip Code: 21000

* Country: France

* Email Address: jean-cyrille.hierso@u-bourgogne.fr

* Website: http://www.icmub.fr/185-membres?r=185&action=view&id=15

About the Research

A project has been initiated at the University of Burgundy based on ligand chemistry for catalysis under ultra-low metal loading. For this purpose, novel polyphosphine ligands based on a ferrocene backbone have been developed (see for example Figure 1). A library of more than fifty ferrocenyl di-, tri- and tetraphosphines has been obtained, from which some ligands displaying outstanding performance have been identified. Carbon–carbon and carbon–nitrogen bond formation (Suzuki, Heck, Sonogashira and Tsuji-Trost reactions) proceeded with high turnover numbers and catalyst loadings as low as 10–4 mol% relative to the substrates.

Fig. 1.

Direct arylation at C3 or C4 of heretoaromatics in the presence of a palladium catalyst with the sterically relieved ferrocenyl diphosphane Sylphos, developed by the Hierso group (Reprinted with permission. Copyright 2012 American Chemical Society)



The mechanistic features of cooperating polydentate ligands are being explored with electrochemistry for measuring kinetics and the identification of intermediary species. Additionally, internationally recognised work has been done in the field of phosphines characterisation through the discovery and investigation of nonbonded ‘through-space’ NMR spin–spin couplings in organophosphorus and organometallic compounds. Recently a patent was deposited, jointly held by the CNRS and the University of Burgundy, on the heterogenisation of a new family of ligands for recycling and heterogeneous catalysis. Low-loading palladium catalysis is now being explored for direct functionalisation of C–H bonds in heteroaromatics and for the formation of C–N, C–O and C–S bonds. C–C coupling for C–H funtionalisation has been achieved in cooperation with Henri Doucet at the University of Rennes, France, and the success of ferrocenyl polyphosphine ligands in low-loading catalysis has led to their commercialisation under the name “HiersoPHOS”.

In addition to the work on screening conditions for palladium-catalysed C–C bond and C–X bond formation (X = S, O, N), iridium and rhodium precursor salts are now also being investigated for direct specific C–H functionalisation.

This fundamental research in synthesis methodology may find many applications in total synthesis or synthesis of fine chemicals, including pharmaceuticals, agrochemicals and molecular materials.

Selected Publications

  1.  J.-C. Hierso, M. Beauperin and P. Meunier, Centre National de la Recherche Scientifique, ‘Supported Ligands Having a High Local Density of Coordinating Atoms’, World Appl. 2012/001,601
  2.  D. Roy, S. Mom, S. Royer, D. Lucas, H. Cattey, J.-C. Hierso and H. Doucet, ACS Catal., 2012, 2, (6), 1033 LINK http://dx.doi.org/10.1021/cs300097v
  3.  M. Platon, L. Cui, S. Mom, P. Richard, M. Saeys and J.-C. Hierso, Adv. Synth. Catal., 2011, 353, (18), 3403 LINK http://dx.doi.org/10.1002/adsc.201100481
  4.  D. Roy, S. Mom, M. Beaupérin, H. Doucet and J.-C. Hierso, Angew. Chem. Int. Ed., 2010, 49, (37), 6650 LINK http://dx.doi.org/10.1002/anie.201002987
  5.  R. V. Smaliy, M. Beaupérin, H. Cattey, P. Meunier, J.-C. Hierso, J. Roger, H. Doucet and Y. Coppel, Organometallics, 2009, 28, (11), 3152 LINK http://dx.doi.org/10.1021/om8012162
  6.  D. Evrard, D. Lucas, Y. Mugnier, P. Meunier and J.-C. Hierso, Organometallics, 2008, 27, (11), 2643 LINK http://dx.doi.org/10.1021/om701279x
  7.  J.-C. Hierso, J. Boudon, M. Picquet and P. Meunier, Eur. J. Org. Chem., 2007, (4), 583 LINK http://dx.doi.org/10.1002/ejoc.200600976
  8.  D. H. Nguyen, M. Urrutigoïty, A. Fihri, J.-C. Hierso, P. Meunier and P. Kalck, Appl. Organomet. Chem., 2006, 20, (12), 845 LINK http://dx.doi.org/10.1002/aoc.1130
  9.  J.-C. Hierso, A. Fihri, R. Amardeil, P. Meunier, H. Doucet and M. Santelli, Tetrahedron, 2005, 61, (41), 9759 LINK http://dx.doi.org/10.1016/j.tet.2005.06.065
  10.  J.-C. Hierso, A. Fihri, R. Amardeil, P. Meunier, H. Doucet, M. Santelli and V. V. Ivanov, Org. Lett., 2004, 6, (20), 3473 LINK http://dx.doi.org/10.1021/ol048870z
  11.  J.-C. Hierso, A. Fihri, R. Amardeil, P. Meunier, H. Doucet, M. Santelli and B. Donnadieu, Organometallics, 2003, 22, (22), 4490 LINK http://dx.doi.org/10.1021/om0302948
